Traffic Light Controller Sequencer Board 3 Channel AC Voltage 100-240VAC 50HZ 60HZ RED Green Yellow RYG AC Light Control NO Coding Required

Title: SSR Manual Traffic Light Sequencer - AC Power, 37+ Sequences, 3 Seven-Segment Displays
Description: Take control of your traffic lights with our SSR Manual Traffic Light Sequencer, an advanced device designed for precision and ease of use. This versatile sequencer offers over 37 sequences, including realistic traffic patterns, random modes, solid-on settings, and customizable sequences. With three built-in seven-segment displays, programming is made simple.

Key Features:
•    Compatible with all LED and incandescent lights, including vintage traffic signals.
•    Wide voltage range: 80VAC to 240VAC.
•    Robust performance: Supports up to 2 Amps per channel over an extended period at 110V/240V AC.
•    Quiet operation: Guaranteed to work silently with all lights.
•    Handles full-sized incandescent traffic lights and low-power LED bulbs (down to 1 watt) without flickering or glowing when turned off.
•    Solid-state technology ensures quiet and reliable operation over the long term, surpassing mechanical relays in performance and longevity.

Efficient Power: This sequencer operates on standard AC voltage, sharing the same input with your AC load or lights, eliminating the need for extra connections. The logic section is energy-efficient and spike-protected, using only about 1/10 watt.
Sequences and Timing: Choose from 37+ pre-programmed sequences with ease using the rotary switch, without the need to power off the device. Sequence memory is retained even during power outages. Explore realistic traffic modes, random sequences, and engaging chaser sequences, with timing adjustments ranging from 1 second to 255 seconds.
Quick and Easy Installation: Installation is straightforward with included instructions.

Specifications:
•    PCB board dimensions: 90mm x 100mm
•    PCB Board Material: 1.6mm FR-4, with solder mask & silk screen.
•    Supply Voltage: Supports 100VAC to 240VAC (50Hz and 60Hz).
•    Delay Range: 0 – 255 seconds for each color (RED, YELLOW, and GREEN), mode-dependent.
•    Input Connector: Utilizes 14-26AWG, 250VAC @ 16A screw terminals.
•    Output Connectors: Utilizes 14-26AWG, 250VAC @ 16A screw terminals.
•    Unit Weight: Approximately 100 grams.

Elevate your traffic light control with precision and convenience using our SSR Manual Traffic Light Sequencer. Explore a wide range of sequences and timings while enjoying easy installation and compatibility with all types of lights. Upgrade your traffic management today!

Please see below link for manual, specs, mode setups
https://drive.google.com/open?id=1WJw1MFEO3u38vmyARW8klY_uvmkNRhIj
Device specification - https://drive.google.com/open?id=1lxucukoVGUECSFD1mO5lTn-1vh3cfgFp
Device setup - https://drive.google.com/open?id=1aqU01qnqoNf6T7nf6FIvItSyykdt4-GH
Traffic Light MODES - https://drive.google.com/open?id=1pVBfBiXSO1FYwh1quGiuo2fs-JBSJvb1
See Device Video in action - https://www.youtube.com/watch?v=0FNbJk5y5dM
How to program
https://www.youtube.com/watch?v=-b9_82diEIs&feature=youtu.be
